Colorimeters & Photometers

Thermo Scientific Orion AQUAfast IV® AQ4000 Field Colorimeter

The Orion AQUAfast IV® AQ4000 multi-wavelength colorimeter stores up to 189 pre-programmed methods. A simple upload procedure updates the colorimeter with the most current programs. The upload keeps the AQ4000 always current.

The Orion AQ4000 features Auto-ID, which when used with Orion Auto-Test cuvettes, automatically identifies the species to be measured, selects the method, wavelength and reaction timer. The user never needs to push a button! The Auto-ID ensures the reagent is matched to the method.

This rugged and attractive unit is waterproof to IP67 standards. It is so advanced that a user can create a custom method and customize calibration. Up to 5 data points can be used to define a custom method. Ten custom methods can be stored in the colorimeter's memory. The simple interface steps a user through setup and measurement.

Thermo Orion AQUAfast IV® AQ4000 Specifications
Thermo Orion AQUAfast IV® AQ4000 Instruction Manual

LaMotte SMART 2 Colorimeter

The user-friendly SMART 2 Colorimeter is the direct reading colorimeter for complete on-site water analyses.
All of the 50 pre-programmed tests can be run on this compact instrument and each test features automatic wavelength selection. The entire multi-LED optical system is embedded in the light chamber and optimized for LaMotte test reagent systems. This enables the analyst to simply select the test and put in the sample with reagent. The microprocessor, which selects the wavelength, also allows the user to load up to 10 tests for analyzing custom reagent systems.

• Menu-driven display
• 85 pre-programmed tests with 10 user tests
• Automatic wavelength selection
• The SMART 2 Colorimeter is supplied with 4 sample tubes, AC adapter, and instruction manual including test procedures.

LaMotte SMART 2 Colorimeter Specifications
LaMotte SMART 2 Colorimeter Operator's Manual
LaMotte SMART 2 Colorimeter Test Instructions

LaMotte ColorQ DW Photometer

ColorQ DW Photometer kit (Code 2059) is the ultimate on-site, hand-held photometer for testing drinking water.

• The large digital display eliminates the guesswork with traditional color matching methods.
• Measures 7 factors important to the drinking water professional including:
  1. Hardness
  2. pH
  3. Iron
  4. Nitrate
  5. Free Chlorine
  6. Total Chlorine
  7. Sulfide
• Kit #2059 includes the ColorQ DW photometer, testing solutions, illustrated instructions and a sturdy carrying case.
• Easy to use
• Clear digital display in ppm
• No guesswork with a comparative chart

LaMotte ColorQ DW Photometer Specifications
LaMotte ColorQ DW Photometer Manual

YSI 9300 & 9500 Photometers

YSI’s new line of photometers includes the Model 9300 and 9500. Eliminate sample preservation by taking your portable, waterproof instruments to the field to perform the analysis on-site. All reagents are safe and easy to use.

Selecting the desired test has never been easier. Simply navigate among the list of available tests on the screen of the instruments to choose your test and say “OK”. The instrument will then walk you through the steps to complete the test. Simple. Convenient. Accurate.

Models 9300 and 9500:

• Direct-reading concentrations with automatic setup
• Waterproof; IP67 (floats)
• Large backlit graphic display
• Unique sample tube holder accommodates
  various diameters
• On-screen instructions
• Multiple languages (English, French, German, Spanish, Italian)
• 100+ test choices on the photometer display

Model 9500 only:

• Waterproof USB connection
• Power via USB port
• Internal Memory - 500 sample sets
• User-Selectable Options: test units, sample number, dilution factors

YSI 9300 & 9500 Photometer Specifications
YSI 9300 Photometer Instructions
YSI 9500 Photometer Instructions
